Each handle has a Backplate sized 170 x 48 x 9mm; Handle length is 109mm with a total projection of 53mm;
Dimensions: Diameter: 52mm and Thickness: 10mm Satin Stainless Steel (as shown);Polished Stainless Steel;Satin / Polished Stainless Steel;Oil Rubbed Bronze.
Dimensions:Handle Length: 127mm Rose: Diameter: 53mm Thickness: 11mm Total Projection: 56mm
Product Dimensions:037C0361_1CLength: 165mm;C to C: 101mm;037C0361_1BLength: 216mm;C to C: 152mm;037C0361_1ALength: 267mm;C to C: 203mm;Available in Multiple Finishes
Product: C2231 96Length: 113mmC to C: 96mmProjection: 35mmProduct: C2231 152Length: 169mmC to C: 152mmProjection: 35mmProduct: C2231 203Length: 220mmC to C: 203mmProjection: 35mm
Dimensions:037C0337_54DLength: 116mm;C to C: 96mm;037C0337_54CLength: 172mm;C to C: 152mm;037C0337_54BLength: 223mm;C to C: 203mm;037C0337_54ALength: 274mm;C to C: 254mm;
Winchester Fixed "D" Handle Cream/Antique Brass128mm Centre Holes 152mm Length 23mm Thick 24mm Base 39mm Projection
Dimesnions: Width: Fastener Back Plate 22mm, Hook Back Plate 17mmHeight: Both Back Plates 67mmAvailable in Multiple Finishes
Dimensions:150, 200, 250, 300, 450 or 600mm x 41mmAvailable in Brass ( Polished and Unlacquered), Polished Chrome, Satin Chrome, Satin Nickel
Size - 155x107x19mm overall39mm to Keyhole110mm spindle backsetAvailable in multiple finishes and either handed LEFT or RIGHT handed.
